· Current Rating: 3A Max. AC/DC
· Poles: 02~16
· Wire Range: AWG#22~26
In modern vinegar production facilities, the submerged fermentation is the pre-dominant process. High performance aeration systems guarantee a homogenous and uninterrupted supply of oxygen to the fermenter, therefore optimally supporting the growth of the microroganisms. In Cetotec fermenters you can achieve up to 15% acidity when applying the semi-batch process as well as more than 20% acidity when applying the fed-batchprocess.
· Current Rating:3A Max. AC/DC
· Voltage Rating:125V Max. AC/DC
· Contact Resistance:<25mΩ
· Insulation Resistance:≥ 100MΩ
· Withstanding Voltage:500V AC/Minute
· Wire Range:AWG# 22~26
· Temperature Range:-40°C~+125°C
| Item | Part No. | Material | Poles | QTY |
|---|---|---|---|---|
| Housing | 1278HI-XXX-LPGWO5BTV 1278HI-XXX-LPGWO5BT | LCP UL94V-0 | 02~16 | TV: 360PCS/Tray TR: 312PCS/Tra |
| Wafer | 1278WRS-XX-LPGWO1BRS 1278WVS-XX-LPGWO1BC | LCP UL94V-0 | 02~16 | WRS: 1000PCS/Reel WVS: 650PCS/Reel |
