· Current Rating: 6A Max. AC/DC
· Poles: 2PIN&4PIN
· Wire Range: AWG#18-28
Height and width of conductor crimp core should be set as required. (conductor crimp height and width of conductor barrel) According to the external diameter and the type of electric wire, the width of crimped sheath shall be adjusted, wirewon’tbe easily taken off from contact nor too much crimped. (Crimped width of insulation barrel)
· Current Rating:6A Max. AC/DC
· Voltage Rating:250V Max. AC/DC
· Contact Resistance: 20mΩ
· Insulation Resistance:≥ 1000MΩ
· Withstanding Voltage:1500V AC/Minute
· Wire Range: AWG# 18-28
· Temperature Range: -40°C~+105°C
| Item | Part No. | Material | Poles | QTY |
|---|---|---|---|---|
| Female Terminal | 3300TXF-PSW1 | Phosphor bronze | -- | 10000PCS/Reel |
| Male Terminal | 3300TXM-PSW1 | Phosphor bronze | -- | 10000PCS/Reel |
| Female Housing | 3300HF-XX-PTXX | PBT UL 94V-0 | 2PIN&4PIN | 1000PCS/Bag |
| Male Housing | 3300HM-XX-PTXX | PBT UL 94V-0 | 2PIN&4PIN | 1000PCS/Bag |
| TPA | 3300C-XX-PTBR | PBT UL 94V-0 | 2PIN&4PIN | 1000PCS/Bag |
