· Current Rating: 3A AC/DC
· Poles: 2*04
· Wire Range: --
Height and width of conductor crimp core should be set asrequired
(conductor crimp height and width of conductor barrel)
wire, the width of crimped sheath shall be adjusted, wire won'tAccording to the external diameter and the type of electric
be easily taken off from contact nor too much crimped.
(Crimped width of insulation barrel)
· Current Rating: 3A AC/DC
· Voltage Rating: 100V Max. AC/DC
· Contact Resistance: < 1OmO
· Insulation Resistance: > 100MO
· Withstanding Voltage: 1000V AC/minute
· Wire Range:Temperature Range: -40°C~+125°C
| Item | Part No. | Material | Poles | QTY |
|---|---|---|---|---|
| Wafe | 2039W-G0809-05H00 | PBT UL94V-0 | 2*04 | 40PCS/tray |
| Housing | 2039AM-2*04B-PTXX | PBT UL94V-0 | -- | 500Pcs/Bag |
| Terminal | 2039TF-H0500 | High Conductivity Coppe | 2*04 | -- |
